An illustrated dictionary of architecture.
One word, drawn and explained.
Each entry is a short film: a part of a building, drawn from a 3D model in pencil and marker and taken apart until it explains itself. Around each entry sit its cousins, the same idea under other names in other places.
The films
Nº 001 · Film out
cumba
A room that borrows space from the street.
Nº 002 · Film out
engawa
An edge that joins a house to its garden.
Nº 003 · Film out
badgir
A tower that catches the wind.
Nº 004 · Film out
hórreo
A granary that stands on tiptoe.
Nº 005 · Film out
pilotis
Columns that give the ground back.
Nº 006 · Film out
flying buttress
An arm that holds a wall from outside.
Nº 007 · Film out
impluvium
A pool that drinks the rain.
Nº 008 · Film out
brise-soleil
Sunglasses for a building.
Nº 009 · Film out
mashrabiya
A window that breathes.
Nº 010 · Film out
dogtrot
A house split by the breeze.
Nº 011 · Film out
jali
A stone wall that turns sunlight into lace.
Nº 012 · Film out
hypocaust
A floor raised on pillars to let fire flow underneath.
Nº 013 · Film out
oculus
A circular opening at the crown of a dome that turns sunlight into a moving dial.
ComingNº 014 · Coming
iwan
A vaulted hall walled on three sides and open to the courtyard on the fourth.
ComingNº 015 · Coming
muqarnas
A tiered honeycomb of niches that bridges a square room to a round dome.
ComingNº 016 · Coming
ondol
A Korean floor warmed by the smoke of the kitchen fire.
ComingNº 017 · Coming
dougong
An interlocking wooden bracket cluster that carries deep eaves without nails.
ComingNº 018 · Coming
riad
An inward-looking courtyard house built around a four-part garden and fountain.
ComingNº 019 · Coming
loggia
A roofed gallery recessed into a building and open to the air through an arcade.
ComingNº 020 · Coming
trullo
A dry-stone house roofed with a cone of overlapping limestone slabs.
